Three-Piece Flange Ball Valve

Inquiry Now
Share:
  • Product Name  3PC Flanged End Ball Valve
    Material  304/316/B62/2207/2507/316ti/C95800, etc.
    Size  1/2”-48”(DN25-DN1200)
    Working Pressure  150LB/300LB/600LB
    Type Floating Ball Valve
    Ball Floating Solid Ball
    Seat Material PTFE, Ptstainless Steel
    Working Temp. -20ºC~180ºC
    Port Full Port
    Suitable Medium  Water, Natural Gas, Oil and some corrosive liquid
    Operated Manual Worm Gear, Pneumatic actuator, Electric Actuator
    Features  Investment casting,Blow-out proof stem,Anti-static device(option)
    Connection Ends RF
    Manual option  Manual
    Design standard  API6D/API608/API607
    Inspection & Testing According  API598
